Techfine MPPT Solar Charge Controller 60a 12/24v/36v/48v for Solar System
Solar Charge Controller

Techfine MPPT Solar Charge Controller 60a 12/24v/36v/48v for Solar System

Tips:

Can support WIFI/ GPRS12/24/3648Vadaptive
Send Inquiry

Product Highlights

Key Features

01

Product Description

Techfine MPPT Solar Charge Controller 60A | 12V/24V/36V/48V MB Series Get maximum solar efficiency with the Techfine MPPT Solar Charge Controller 60A, designed for flexibility and performance in various solar setups. This controller offers a 12V/24V/36V/48V adaptive range, making it an ideal solution for those looking to maximize solar energy management across different system voltages. With support for both lead-acid and lithium battery types, this versatile MPPT charge controller ensures optimal charging with three-stage smart charging technology, which protects and extends battery life. Featuring adjustable parameters and intuitive controls, this 60A MPPT solar charge controller also includes optional WiFi and GPRS support for enhanced monitoring capabilities. Its powerful MPPT solar charge technology efficiently manages the power supply, making it perfect for both residential and commercial solar systems. Whether you need a 12V/24V or 36V MPPT solar charge controller, Techfine’s MB Series has you covered for reliable solar performance.

Specifications

Factory model60415
System voltage12V/24V/36V/48V(Adaptive)
Rated current60A
Charging modeMPPT maximum power point tracking
Applicable battery typeSealed maintention-free lead-acid battery (default), colloidal lead-acid battery, open lead-acid battery (can also customize parameters for other types of battery charging)
Charging modeThree stages: constant current, constant pressure, floating charge
Pv Input Maximum Open Circuit Voltage (VOC)DC150V(minimum temperature) DC138V (25℃ standard temperature)
Start-up time≤10s
Dynamic response recovery time≤500us
Static power consumption
Tracking efficiency≥99.5%
Maximum conversion efficiency≥98%
The controller system identifies the operating voltage range8～64V
Maximum power point operating voltage range12V system20～150VDC
24V system36～150VDC
36V system48～150VDC
48V system64～150VDC
Rated charging power12V800W
24V1600W
36V2400W
48V3200W
96V/
Load voltageCobattery voltage
Rated load current40A
Load control modeNormally on normally off mode/time control mode/light control mode
Load undervoltage protectionThe default value is 10.5V x N (N is the number of batteries)
Heat dissipation modeAir cooling
Display modeHd LCD backlight display
Protection functionInput and output over and under voltage protection, input and output anti-reverse protection, machine over temperature protection, load over current protection
Temperature compensation coefficient-3mV/℃/2V
Communication modeRS485
Operating ambient temperature-20℃～+50℃
Storage temperature-40℃～+70℃
Noise≤50dB
Humidness0～90%RH
Altitude0～3000M
